• 2D Floor Plans & 3D Elevation Design
• Architectural Design – All necessary Working Drawings
• Interior Design - 2D furniture layout
• Structural Design – Structural Design & GFC Drawings
• MEP Design – Electrical, Plumbing Water line & Drainage line layouts

• Floor to floor height - 10ft
• Steel (500 TMT Bars) – Bhuwalka/Kamadhenu
• Cement (Grade 53) – ACC/Birla/Penna/Dalmia
• UG Sump built with solid blocks of 6” thickness & waterproof plastered
• Concrete – M20 grade RMC
• Solid Block walls - 6” & 4” thickness
• Internal, external and toilet wall - column joints plastering with chicken mesh
• Crystalline waterproofing, Cinder filling in sunken toilets, Heat & Waterproofing in Terrace
• Concealed Sanitary fixtures or its subsequent provisions like ledge walls are not included
• Steel/concrete lofts - Not included

• Living, Kitchen, Dining & Bedrooms : Vitrified tiles - Rs.50/- per Sqft
• Staircase & Foyer Area : Granite - Rs.90/- per Sqft
• Balcony, Sit-out, Passage Areas : Anti-skid tiles - Rs.35/- per Sqft
• Toilet Flooring : Anti-skid tiles - Rs.40/- per Sqft
• Toilet Wall Dado (7ft height) : Highlighting Tiles - Rs.40/- per Sqft
• Parking Area : Parking tiles - Rs.35/- per Sqft
• Kitchen counter top : Granite - Rs.100/- per Sqft
• Kitchen Wall Dado (Up to 2’ above counter) : Backsplash tiles - Rs.40/- per Sqft
• Puja Room Wall tiling – Not Included

• Internal wall & ceiling : wall putty + primer coat + latest Tractor emulsion paint
• External walls : primer coat + ace weather proof paint
• Brand : Asian/Berger/Dulux

• Light & power points – as per electrical design
• Geyser points – All bathrooms
• AC provision – Any 1 room
• Conduits – Good quality, hidden in slabs and walls
• Copper wire –Anchor
• External electrification is included
• Switches & Plates – Anchor - Ziva make
• A main DB & MCB - IndoAsian make

• Water supply system – Internal & External
• Connection for water inlet from corporation
• External sewage system – Inspection chambers & sewage outlet to manhole
• Class B CPVC pipes – Astral/Supreme make
• Solar & Geyser Provision
• Rain water harvesting facility – Ground water recharge
• PVC Overhead Tank – Ganga/Equivalent make

• Kitchen sink : SS/Granite/Carysil - Rs.2500/- per sink
• Kitchen accessories – Rs. 2,000/-
• CP & Sanitary fixture : Cera/Hindware/Equivalent - Rs.15,000/- per toilet
• Electrical fixtures - Not Included

• Main Door : Teak Wood frame & shutter including hardware - Rs.16,500/- per door
• Internal Doors : Any wood frame & shutter including cost of hardware - Rs.9,000/- per door
• Internal Door frames & shutters – Painted (only)
• Main Door - Polished with melamine by hand
• Bathroom Door - Frame & shutter including hardware - Rs.7,500/- per door
• Door hardware – Ozone/Europa/Dorma make.
• Door hinges - SS hinges
• Door & Door Frame cost - Inclusive of planing, rebate, transportation etc.

• Aluminium windows - 5mm clear glass with MS Grills
• Basic price : Aluminium windows including MS grills - Rs 400/- per Sqft
• Percentage of opening for windows - 12% Maximum

• Main Gate: MS Gate - Rs.270/- per Sqft
• Internal, External & Balcony railing: MS railings - Rs.160/- per Sqft
• Utility grill – Only for ground floor home

not including

• This proposal includes basic elevation design for your home
• A 3D elevation is presented for client to choose from & design
• Elevation can be designed & more elements may be added at very nominal cost to the design

• Government fees for the liaison bodies to be paid directly by the client
• Assuming the site & road level to be equal, if the ground level needs to be raised above 18”, it shall be charged for accordingly
• Hard rock /soft rock excavation, if it arises shall be charged for accordingly
• Buying new earth/sending existing earth for excavation/backfilling purpose shall be charged on actual
• Basic price of Cement is Rs.350/- per bag & Steel is Rs.50,000/- per MT. Any increase in these prices shall be charged accordingly
• Any work not mentioned within this package or outside the site boundary shall be charged for accordingly
• One point of Electricity & water needs to be provided by the client free of cost to facilitate construction
• SBC of soil is considered at 180 KN/M2 and depth of the foundation considered at 5 Feet, any increase in depth shall be charged accordingly on actuals upon site conditions
• A specific area to construct labour and material shed needs to be provided within 50 feet from the construction place by the client

• Construction guarantee – 1 Year
• Waterproofing warranty – 10 Years
• Guarantee & warranty is provided on Stamp paper

• 2D Floor Plans & 3D Elevation Design
• Architectural Design – All necessary Working Drawings
• Interior Design - 2D furniture layout, assistance in material procurement, 3D interior designs if executed by BAH
• Structural Design – Structural Design & GFC Drawings, soil test report, Design analysis report
• MEP Design – Electrical, Plumbing Water line & Drainage line layouts
• Internal isometric views – All rooms, open areas etc.

• Floor to floor height - 10'6"
• Steel (500 TMT Bars) – Bhuwalka/Kamadhenu
• Cement (Grade 53) – ACC/Birla/Penna/Dalmia
• UG Sump built with solid blocks of 6” thickness & waterproof plastered
• Concrete – M20 grade RMC
• Solid Block walls - 6” & 4” thickness
• Internal, external and toilet wall - column joints plastering with chicken mesh
• Waterproofing compound - Dr.Fixit/FOSROC for external walls
• Crystalline waterproofing, Cinder filling in sunken toilets, Heat & Waterproofing in Terrace
• Ledge wall for incorporating concealed sanitary parts - Included
• Steel/concrete lofts - Not included

• Kitchen & Bedrooms : Vitrified Tiles - Rs.65/- per Sqft
• Living Room, Dining : Marble finished vitrified tiles -Rs.80/- per Sqft
• Staircase & Foyer Area : Granite - Rs.100/- per Sqft
• Balcony, Sit-out, Passage Areas : Anti-skid tiles - Rs.50/- per Sqft
• Toilet Flooring : Anti-skid tiles - Rs.50/- per Sqft
• Toilet Wall Dado (Full Height) : Highlighting Tiles - Rs.50/- per Sqft
• Parking Area : Parking tiles - Rs.40/- per Sqft
• Kitchen counter top : Granite - Rs.120/- per Sqft
• Kitchen Wall Dado (Up to 2’ above counter) : Backsplash tiles - Rs.55/- per Sqft
• Puja Room Wall tiling – Not Included

• Internal wall & ceiling : wall putty + primer coat + latest Tractor emulsion paint
• Living & dining room : Premium emulsion
• External walls : Primer coat + external Apex weather proof paint
• Brand : Asian/Berger/Dulux

• Light & power points – as per electrical design
• Geyser points – All bathrooms
• AC provision – Any 2 room
• Conduits – Good quality, hidden in slabs and walls
• Fire proof copper wire – Finolex or Polycab
• External electrification is included
• Switches & Plates – Anchor-Roma make
• A main DB & MCB – IndoAsian/Siemens/Equivalent make
• Electric Car charging point – Parking area

• Water supply system – Internal & External
• Connection for water inlet from corporation
• External sewage system – Inspection chambers & sewage outlet to manhole
• Class B CPVC pipes – Ashirwad/Astral make
• Solar & Geyser Provision
• Rain water harvesting facility – Ground water recharge
• PVC Overhead Tank – Sintex/Equivalent make

• Kitchen sink : SS/Granite/Carysil - Rs.5000/- per sink
• Kitchen accessories – Rs. 4,000/-
• CP & Sanitary fixture : Jaquar/Hindware - Rs.22,000/- per toilet
• Electrical fixtures - Not Included

• Main Door : Teak Wood frame & shutter including hardware - Rs.25,000/- per door
• Internal Door - Sal wood frame & shutter including hardware - Rs.12,000/- per door
• Internal Door frames & shutters – Painted (only)
• Puja Door - Polished with melamine spray
• Bathroom Door - Frame & shutter including hardware - Rs.9000/- per door
• Door Hardware – Ozone/Europa/Dorma make
• Door hinges - SS hinges
• Door & Door Frame cost - Inclusive of planing, rebate, transportation etc.

• UPVC windows - 5mm clear glass with MS Grills
• Basic price : uPVC with MS grill - Rs.570/- per Sqft
• Percentage of opening for windows – 18% Maximum

• Main Gate: MS Gate - Rs.360/- per Sqft
• External staircase & balcony railing : MS Railing - Rs. 160/- per Sqft
• Internal staircase railing : SS Railing – Rs.280/- per Sqft
• Utility grill – Ground floor home only

• Compound wall - Solid block walls of 4” thickness to suit the elevation.
• Paraphet wall
• Excavation, Foundation, PCC, Size Stone Masonry with DPC course above SSM
• Height of Compound wall above DPC course – 5 Feet
• Compound wall – Plastered & Painted

• This proposal includes aethetically pleasing elevation.
• A 3D elevation is presented for client to choose from & design further
• Elevation budget - Rs 30/- per Sqft of floor area
• Texture painting, tile cladding, shera cladding or any similar features can be chosen

• Government fees for the liaison bodies to be paid directly by the client
• Assuming the site & road level to be equal, if the ground level needs to be raised above 18”, it shall be charged for accordingly
• Hard rock /soft rock excavation, if it arises shall be charged for accordingly
• Buying new earth/sending existing earth for excavation/backfilling purpose shall be charged on actual
• Basic price of Cement is Rs.350/- per bag & Steel is Rs.50,000/- per MT. Any increase in these prices shall be charged accordingly
• Any work not mentioned within this package or outside the site boundary shall be charged for accordingly
• One point of Electricity & water needs to be provided by the client free of cost to facilitate construction
• SBC of soil is considered at 180 KN/M2 and depth of the foundation considered at 5 Feet, any increase in depth shall be charged accordingly on actuals upon site conditions
• A specific area to construct labour and material shed needs to be provided within 50 feet from the construction place by the client

• Construction guarantee – 1 Year
• Waterproofing warranty – 10 Years
• Guarantee & warranty is provided on Stamp paper

• Premium 2D & 3D Floor plans & Luxury 3D Elevation design of all views
• Architectural- All necessary Working Drawings, Detailed Landscaping, Detailed portfolio post-handover
• Interior design- 2D furniture layout, Complete 3D designs (if executed by BAH only)
• Structural- Structural design & GFC drawings, Design Analysis Report
• MEP- Electrical layout, Plumbing Water & Drainage layouts, Detailed HVAC layout
• 3D design- Internal Isometric Views of all areas & detailed renders to understand design better, Hands on isometric 3D model of the home, 3D walkthrough of the home

• Floor to floor height - 11'
• Steel (500 TMT Bars) – JSW/SAIL/Vizag
• Cement (Grade 53) – ACC/ Ultratech
• UG Sump built with RCC & waterproof plastered
• Concrete – M20 grade
• Solid Block walls (of APCO or similar) - 8” & 4” thickness.
• Internal, external and toilet wall - column joints plastering with chicken mesh
• Internal courtyards, skylights other designer architectural elements are included
• Waterproofing compound - Dr.Fixit/FOSROC for external walls
• Crystalline waterproofing, Cinder filling in sunken toilets, Heat & Waterproofing in Terrace
• Ledge wall for incorporating concealed sanitary parts is included
• Steel/concrete lofts are included

• Kitchen & Bedrooms : Vitrified Tiles - Rs.90/- per Sqft
• Living Room, Dining – Italian Marble - Rs.380/- per Sqft
• Staircase & Foyer Area : Granite - Rs.100/- per Sqft
• Balcony, Sit-out, Passage Areas : Anti-skid tiles - Rs.65/- per Sqft
• Toilet Flooring : Anti-skid tiles - Rs.65/- per Sqft
• Toilet Wall Dado (Full Height) : Highlighting Tiles - Rs.70/- per Sqft
• Parking Area – Parking tiles/Designer Pavers - Rs.65/- per Sqft
• Kitchen counter top – Granite - Rs.150/- per Sqft
• Kitchen Wall Dado (Up to 2’ above counter) – Backsplash tiles - Rs.60/- per Sqft

• Internal wall & ceiling – wall putty + primer coat + latest Premium Emulsion paint
• External walls – primer coat + external Apex Ultima weather proof paint
• Brand : Asian/Berger/Dulux
• Texture Painting as shown in the elevation

• Light & power points – as per electrical design
• Geyser points – All bathrooms
• AC provision – All rooms
• Conduits – Good quality, hidden in slabs and walls
• Fire retardant copper wire – Havells
• External electrification is included
• Switches & Plates – Legrand/ABB make (Touch screen switch provision)
• A main DB & MCB – ABB/Schneider/Legrand make
• Electric Car charging point – Parking area

• Water supply system – Internal & External
• Connection for water inlet from corporation
• External sewage system – Inspection chambers & sewage outlet to manhole
• Class B CPVC pipes – Ashirwad/Astral make
• Solar & Geyser Provision
• Rain water harvesting facility – Ground water recharge
• RCC Overhead Tank

• Kitchen sink: SS/Granite/Carysil - Rs. 10,000/- per sink
• CP & Sanitary fixtures : Jaquar/Hindware - Rs.35,000/- per toilet
• Electrical Fixtures – Not included

• Main Door : Teak Wood frame & shutter including hardware - Rs.50,000/- per door
• Internal Door - Sal wood frame & shutter including hardware - Rs.15,000/- per door
• Internal Door - Sal wood frame & shutter including hardware - Rs.15,000/- per door
• Main, Puja Door - Polished with PU finish spray
• Bathroom Door - Frame & shutter including hardware - Rs.11,000/- per door
• Door Hardware – Ozone/Europa/Dorma make
• Door hinges - SS hinges
• Door & Door Frame cost - Inclusive of planing, rebate, transportation etc.

• UPVC windows (Fenesta or equivalent) - 5mm clear glass with MS Grills
• Basic price: uPVC with MS grill or wooden including hardware - Rs.810/- per Sqft
• Wooden windows – Honne Frame (5”x3”) & Shutter (1.5” thickness) with clear glass and grill rods

• Main Gate: Designer Gate with Shera boards - Rs. 450/- per Sqft
• External staircase & balcony railing: MS Railing - Rs. 180/- per Sqft
• Internal staircase railing: SS Railing with Glass – Rs.450/- per Sqft
• Utility grill – Ground floor home only

• Compound wall - Solid block walls of 4” thickness to suit the elevation.
• Paraphet wall
• Excavation, Foundation, PCC, Size Stone Masonry with DPC course above SSM
• Height of Compound wall above DPC course – 5 Feet
• Compound wall – Plastered & Painted

• This proposal includes luxurious elevation
• A 3D elevation is presented for client to choose from & design further
• Elevation budget - Rs 55/- per Sqft of floor area
• Stone cladding, fundermax, premium landscape & planter boxes, royal paint, glass railing, sandstone or similar cladding, CNC cut frames etc. or any similar features can be chosen

• Government fees for the liaison bodies to be paid directly by the client
• Assuming the site & road level to be equal, if the ground level needs to be raised above 18”, it shall be charged for accordingly
• Hard rock /soft rock excavation, if it arises shall be charged for accordingly
• Buying new earth/sending existing earth for excavation/backfilling purpose shall be charged on actual
• Basic price of Cement is Rs.380/- per bag & Steel is Rs.55,000/- per MT. Any increase in these prices shall be charged accordingly
• Any work not mentioned within this package or outside the site boundary shall be charged for accordingly
• One point of Electricity & water needs to be provided by the client free of cost to facilitate construction
• SBC of soil is considered at 180 KN/M2 and depth of the foundation considered at 5 Feet, any increase in depth shall be charged accordingly on actuals upon site conditions
• A specific area to construct labour and material shed needs to be provided within 50 feet from the construction place by the client

• Construction guarantee – 1 Year
• Waterproofing warranty – 10 Years
• Guarantee & warranty is provided on Stamp paper
